The DOBOT Mini Air Pump Box is a portable plug-and-play air source that allows flexible deployment anywhere.
Product Highlights
- Plug & play: Eliminate the need for pneumatic circuit design and modification and create a movable unit workstation.
- Easy to use: Supports two control modes - manual mode and I/O mode, making operation easy.
- Cost-effectiveness: Saves costs and yields high returns.
Application
- Use with other pneumatic tools to add pressure to grippers to complete tasks such as grabbing and transportation of objects.
Specification
| Mini Air Pump Box |
|---|
| Model | Mini Air Pump Box |
| Range of Air Pressure | -70 ~ 110 kPa |
| Control Method | I/O |
| Diameter of Air Hose Connector | Φ4 mm |
| Dimensions | 163 mm × 143 mm × 53 mm |
| Weight | 800 g |
| IP Rating | IP20 |
| Noise | 65 dB |
| Rated Voltage | 24V DC ±10% |
| Rated Current | 0.8A |
| Max Current | 1.2A |
